Ray bi 3 tầng Nhấn mở /Push-to-open ball Bearing Slides
-
0
-
Liên hệ
-
1196
Usage: Kitchen Cabinet
Type: Slide
Material: Cold Rolled Steel, Work hardened cold rolled steel
Product Mount Method: Side Mounting
Function: Push - to - open
Characteristers: Inner frame detachable assembly function,adopt 32mm system hole.
Load capacity: 35kgs
Specification: 14 inch-24inch(350mm-600mm)
Width: 45mm
Gap: Gap of every side is 12.7+_0.2mmmm
Finish: Electro-zinc plated with clear,yellow or black chromate.
Thickness of material(O/M/I): 1.2*1.2*1.5mm
Type: Slide
Material: Cold Rolled Steel, Work hardened cold rolled steel
Product Mount Method: Side Mounting
Function: Push - to - open
Characteristers: Inner frame detachable assembly function,adopt 32mm system hole.
Load capacity: 35kgs
Specification: 14 inch-24inch(350mm-600mm)
Width: 45mm
Gap: Gap of every side is 12.7+_0.2mmmm
Finish: Electro-zinc plated with clear,yellow or black chromate.
Thickness of material(O/M/I): 1.2*1.2*1.5mm
